Description
Barrier Material: Thermoplastic (UL=94V-0), Black
Terminals: Tint Plated Brass (Standard)
Screws: Nickel Plated Steel
Wire Range AWG: 12-22 STR
Cover Material: PC
Insulation withstands voltage AC 2000V/Min
Pole HD-12-? P HD-12-? PH
A (Px9.5)+1.4 (P+2)*9.5+1.4
B (P-1)*9.5 (P+1)*9.5
Product Specifications
- AC current rating : 25A
- Mounting Method : Panel
- Packaged Volume : 0.03l
- Packaged Weight : 0.02kg
- Packaged Length : 5.8cm
- Packaged Width : 1.5cm
- Packaged Height : 3cm
- Type : Screw Terminal
- Device : Terminal
- Attachment Method : Solder Tag
- Number of Contacts : 4pc
- Terminal Spacing : 9.5mm
- Insulation Dielectric Voltage Rating : 2V
- Insulation Resistance : 500MΩ
| Length : 5.8 cm | Width : 1.5 cm |
| Height : 3 cm |
